Description

The Kenwood TK-2000/TK-3000 series completely eliminates operational confusion by stripping away distracting screens and complex nested menus in favour of a straightforward, 16-channel point-and-talk interface. Measuring a mere 22 mm in depth (excluding the battery pack) and weighing only 203 grams, this pocket-sized series is exceptionally comfortable to carry all day without dragging down uniforms or fabrics.

Constructed around a rigid aluminum die-cast frame encased in a high-impact poly-carbonate resin shell, these radios pass severe military-grade drop, shock, and rain benchmarks Backed by Kenwood’s signature voice-tuned acoustics and a robust battery save framework, the series ensures your staff stays safely connected through the longest shifts.

Features

KEY OPERATIONAL FEATURES
Slim & Lightweight Design Compact, contoured construction provides a comfortable grip and convenient portability. The slim profile and lightweight design make the radio suitable for extended use by security personnel, warehouse staff, hospitality teams and other frontline workers.
Clear Voice Communication Optimised internal speaker and acoustic design deliver clear, dependable voice audio for everyday business communication, including use in environments with moderate background noise.
CTCSS & DCS Signalling Supports Kenwood QT (CTCSS) and DQT (DCS) signalling for selective squelch operation. Helps organise communication groups and reduces unwanted audio from other users operating on the same frequency.
PC Programming & Wired Cloning Supports PC-based programming of operating frequencies, squelch settings and time-out timer functions. Wired cloning enables compatible radio configurations to be copied between units, simplifying fleet setup and management.
Hands-Free VOX Operation Voice-Operated Transmission (VOX) enables hands-free communication when used with compatible audio accessories and appropriate programming. Ideal for personnel who need to communicate while performing other tasks.
Time-Out Timer (TOT) Programmable transmission time-out timer automatically ends a transmission when the configured time limit is reached. Helps prevent prolonged channel occupation caused by an accidentally held Push-to-Talk button.

Specifications

TECHNICAL SPECIFICATIONS
Specification Kenwood TK-2000 (VHF) Kenwood TK-3000 (UHF)
Frequency Range VHF: 144–174 MHz UHF: 400–470 MHz / 440–480 MHz
Depending on model variant
Channel Capacity 16 programmable channels
Rotary channel selector		 16 programmable channels
Rotary channel selector
RF Transmit Power High: 5 W
Low: 1 W		 High: 4 W
Low: 1 W
Channel Spacing 12.5 / 25 kHz 12.5 / 25 kHz
Battery KNB-63L
1130 mAh lithium-ion		 KNB-63L
1130 mAh lithium-ion
Battery Operating Time Up to approximately 10 hours per charge Up to approximately 10 hours per charge
Environmental Protection IP54 dust and splash resistance IP54 dust and splash resistance
Military Durability Standards MIL-STD-810 C/D/E/F/G MIL-STD-810 C/D/E/F/G
Audio Output 500 mW internal speaker
≤ 5% rated distortion		 500 mW internal speaker
≤ 5% rated distortion
Signalling QT (CTCSS) / DQT (DCS) QT (CTCSS) / DQT (DCS)
Programming PC programming
Wired cloning		 PC programming
Wired cloning
Accessory Connector Kenwood-style 2-pin Kenwood-style 2-pin
Dimensions (W × H × D) 54 × 113 × 24.9 mm
With KNB-63L battery		 54 × 113 × 24.9 mm
With KNB-63L battery
Device Weight Approximately 203 g Approximately 203 g

Brochure

tk2000_3000_m

Accessories

COMPATIBLE ACCESSORIES
Battery Packs KNB-63L – Standard rechargeable lithium-ion battery
KNB-65L – High-capacity rechargeable lithium-ion battery
Battery Chargers KSC-35S – Rapid battery charger
KSC-43 – Travel charger
Audio Accessories KMC-45 – External speaker microphone
EMC-7 – Earpiece microphone
EMC-11 – Earpiece microphone
Carrying Accessories KBH-10 – Belt clip
KLH-187 – Soft leather carrying case
Programming Accessories KPG-22 – Programming cable/interface for radio configuration
