Kirisun PT6500 Analog Two-Way Radio

Home>Two-Way Radios>Kirisun PT6500 Analog Two-Way Radio
Kirisun PT6500

Description

The Kirisun PT6500 balances extreme structural toughness with highly versatile signaling options. Constructed around a reinforced aluminum die-cast frame encased in a high-impact, ruggedized poly-carbonate shell, this non-display radio handles severe drops, vibrations, and harsh daily workplace treatment with ease. Pushing out up to 5 watts of raw RF output power, it maximizes communication range and guarantees excellent structural penetration through dense concrete walls or multi-layered steel frameworks. Equipped with an expansive 128-channel capacity and a powerful internal acoustic amplifier, the PT6500 ensures large, multi-department teams stay safely connected and highly productive across expansive facilities.

Features

KEY OPERATIONAL FEATURES
128-Channel Capacity Supports up to 128 programmable channels organised into eight customisable zones. Allows organisations to separate communication groups by department, location or operational function, with convenient access through programmable keys and the channel selector.
Clear & Powerful Audio Voice-optimised acoustic design and a high-performance internal loudspeaker help deliver clear, intelligible communication in demanding working environments, including manufacturing facilities, warehouses, construction sites and outdoor operations.
Advanced Signalling Options Supports CTCSS and DCS signalling alongside 2-Tone, 5-Tone and DTMF functions. Enables compatible selective calling, group paging and Push-to-Talk identification (PTT ID) for improved communication management.
Hands-Free VOX Operation Voice-Operated Transmission (VOX) allows hands-free communication when used with compatible audio accessories. Suitable for personnel who need to communicate while keeping their hands available for operational tasks.
Remote Stun, Kill & Revive Supports compatible over-the-air radio management commands that allow authorised personnel to remotely disable lost, stolen or compromised radios. Revive functionality enables supported units to be reactivated when recovered.
Lone Worker & Emergency Alerts Integrated emergency alarm functionality and a configurable Lone Worker timer help improve employee safety. The Lone Worker function can initiate a programmed alert sequence if the user does not respond or operate the radio within a specified period.

Specifications

TECHNICAL SPECIFICATIONS
Operating Frequency Range VHF: 136–174 MHz
UHF: 400–470 MHz
Available as separate frequency-band models
Channel Capacity 128 programmable channels
Up to 8 customisable zones
RF Transmit Power VHF: 5 W (High) / 1 W (Low)
UHF: 4 W (High) / 1 W (Low)
Programmable high/low power settings
Channel Spacing 12.5 kHz (Narrowband)
25 kHz (Wideband)
Battery Options Standard: 1200 mAh rechargeable NiMH battery pack
Optional compatible lithium-ion battery pack
Battery Management Automatic battery-saving standby mode
Low-battery LED and audible warning indicators
Environmental Protection IP54-rated protection against limited dust ingress and water splashes
Military Durability Standards Tested against applicable MIL-STD-810 C / D / E / F environmental test methods
Audio Accessory Connector Kenwood-style 2-pin accessory connector for compatible earpieces, microphones and headsets
Dimensions (W × H × D) 56 × 120 × 35 mm
Excluding antenna and belt clip projections
Device Weight Approximately 330 g
