| Multiple Scanning Functions: Multi Scanning Function offers wide applicability |
| RF Power Selectable: High/Low Power is selectable |
| CTCSS: Built-in CTCSS encoder/decoder can activate repeater and selective calls. |
| Menu: You can select CTCSS, high/low power and scanning channel by menu. |
| Keypad Lock: Keypad lock can prevent misoperation. |
| VOX: Allos hands free communication. |
| Display: 6 Character alphanumeric LCD display. |
| GENERAL | |
| Frequency | 66 ~ 88 MHz |
| Number of Channels | 256 |
| Channel space | 25KHz, 12.5KHz |
| Operating temperature | -25°C ~ +55°C |
| Antenna impedance | 50 Ω |
| Microphone impedance | 2k Ω |
| Frequency stability | ± 2.5ppm |
| Battery (Standard) | Li-ion 1700mAh |
| Dimensions (mm) | 56 x 120 x 35 |
| Weight (g) | 305 (with battery and antenna) |
| RECIEVER | |
| Sensitivity (12dB SINAD) | 0.25µ V(W), 0.28µ V(N) |
| Operating band width | ± 7kHz(W), ± 3.5kHz(N) |
| Adjacent channel selectivity | ≥ 70dB (W), 60dB (N) |
| Intermodulation reject ratio | ≥ 65dB |
| Spurious response reject ratio | ≥70dB(W), ≥60dB(N) |
| AF output power | 500mW (Distortion less 5%) |
| TRANSMITTER | |
| RF power | 5W / 1W |
| Spurious and harmonics | ≤-70dB |
| FM noise (300~3000Hz) | ≤-40dB(W), ≤-35dB(N) |
| Audio distortion (300~3000Hz) | ≤5% |
| Maximum frequency deviation | ± 5kHz(W), ± 2.5kHz(N) |
