Hytera HR1065 Repeater

Description

The Hytera HR1065 is designed specifically to optimize space-constrained server rooms, mobile command vehicles, and industrial racks. Delivering up to 50 watts of continuous-duty power, its updated internal architecture provides significantly enhanced receiver sensitivity, noticeably pushing the physical range boundaries of connected handhelds and mobile fleets. With an integrated power supply, automatic AC/DC power switching, and built-in IP site connectivity, the HR1065 represents a smarter, more cost-effective way to build or expand a multi-site network.

Features

ADVANCED INFRASTRUCTURE FEATURES
Ultra-Thin 1U Modular Design Features an ultra-slim 1U rack-mount design measuring approximately 44 mm in height. Its space-saving construction allows multiple repeaters to be installed within standard equipment cabinets, increasing communication capacity while reducing rack space requirements.
Continuous-Duty 50 W Transmission Supports adjustable RF output power from 5 W to 50 W with a 100% continuous duty cycle. An advanced heat dissipation system and temperature-controlled cooling fan help maintain reliable performance during extended periods of heavy communication traffic.
Analogue & Digital Mixed Mode Automatically detects and processes compatible analogue or digital transmissions in mixed-mode operation. Allows organisations to transition gradually from analogue to DMR digital communications while maintaining compatibility with existing radio fleets.
Integrated Power Supply & Battery Backup Incorporates an internal 100–240 V AC power supply with support for a connected 12 V backup battery. Integrated battery charging and automatic switching to DC backup power help maintain communications during mains power interruptions, reducing the need for separate backup power equipment.
IP Networking & Converged Gateway Supports Ethernet-based IP networking for connecting repeater sites and extending communication coverage. The Enhanced Model offers additional gateway functionality for integration with compatible SIP telephony, IP-PBX systems and dispatch applications, subject to system configuration and licensing.
Web-Based Browser Management The Enhanced Model provides browser-based management capabilities for convenient remote monitoring and administration of supported repeater functions. Available management features depend on firmware, configuration and system permissions.

Specifications

TECHNICAL SPECIFICATIONS
Frequency Range VHF: 136–174 MHz
UHF: 400–470 MHz
Frequency range depends on the model variant.
Digital Protocol ETSI TS 102 361-1, -2 and -3 (DMR Tier II Conventional Standard).
Channel Capacity 64 channels, expandable up to 1,024 channels on select versions.
RF Output Power Adjustable from 5 W to 50 W, supporting a 100% continuous duty cycle.
Channel Spacing 12.5 kHz / 20 kHz / 25 kHz (switchable configuration).
Receiver Sensitivity Analogue: 0.18 μV (12 dB SINAD)
Digital: 0.20 μV (5% BER).
Operating Voltages AC: 100–240 V (47–63 Hz)
DC: 13.6 V ±15% nominal.
Standby Current Drain DC: ≤ 0.9 A
AC: ≤ 0.35 A.
Full Transmit Current (45 W / 50 W) DC: ≤ 12 A
AC: ≤ 1.2 A.
Rear Interconnect Interfaces RJ45 Ethernet, WAN/LAN ports, USB, transmit/receive antenna connections and accessory interface pins.
Frequency Stability ≤ ±0.5 ppm.
Dimensions (W × H × D) 483 × 44 × 366 mm (19 × 1.73 × 14.4 inches).
Standard 19-inch rack-mount format with 1U height.
Net Unit Weight Approximately 5.8 kg (12.78 lbs).
